Type: Coils & Sheets hot-dipped galvanized
Applications:
- Formatting of sheet for the covering of roofs and side face of metallic structure buildings, external surfaces of movable small houses, parking, bus stations, etc
- Formatting of sheet for the construction of grills, car trailers, downpipes, cable railings, rubbish baskets, etc
- Formatting of sheet for the construction of air pipes, air ventilators for household and industrial use, chimneys, etc
- Formatting of sheet for the construction of movable gratings and the separation of areas
- Formatting of sheet for the construction of pre-galvanized pipes
- Formatting of sheet for decorative constructions
Steal grade: DX51D according to ΕΝ10346
Zinc quality: Z100 (min 100 gr Zn/m2) up to Ζ350 (min 350 gr Zn/m2). Also available coils and sheets whose surface is covered with aluminum-zinc alloy (Aluzinc - Galvalume)
Thickness: Hot-dipped galvanized from 0.25 mm up to 5 mm. Aluzinc (Galvalume) from 0.40 mm up to 1.50 mm
Dimensions: Coil width 1000, 1250, 1500 mm. Sheets 1000 x 2000, 1250 x 2500, 1500 x 3000 mm or according to client’s specifications.
| Thickness (mm) | Weight (kg/m2) | Sheet dimensions mm / Weight kg | ||
|---|---|---|---|---|
| 1000 x 2000 | 1250 x 2500 | 1500 x 3000 | ||
| 0.25 | 1,963 | 3,93 | 6,13 | - |
| 0.30 | 2,355 | 4,71 | 7,36 | - |
| 0.40 | 3,140 | 6,28 | 9,81 | - |
| 0.50 | 3,925 | 7,85 | 12,27 | - |
| 0.60 | 4,710 | 9,42 | 14,72 | - |
| 0.70 | 5,495 | 10,99 | 17,17 | - |
| 0.80 | 6,280 | 12,56 | 19,63 | 28,26 |
| 0.90 | 7,065 | 14,13 | 22,08 | 31,78 |
| 1.00 | 7,850 | 15,70 | 24,53 | 35,33 |
| 1.25 | 9,810 | 19,62 | 30,66 | 44,15 |
| 1.50 | 11,780 | 23,56 | 36,81 | 53,01 |
| 2.00 | 15.700 | 31,40 | 49,06 | 70,65 |
| 2.50 | 19,620 | 39,24 | 61,31 | 88,29 |
| 3.00 | 23,550 | 47,10 | 73,59 | 105,98 |
| 4.00 | 31,400 | 62,80 | 98,13 | 141,30 |
| 5.00 | 39,250 | 78,50 | - | - |
